inoLab
®
Multi 9620 IDS Operation
ba77173e04 12/2017 17
4.1.5 Channel display
The Multi 9620 IDS manages the connected sensors and displays which sen-
sor is plugged to which connection.
4.1.6 Sensor info
You can display the current sensor data and sensor settings of a connected
sensor at any time. The sensor data are available in the measured value dis-
play with the /[Info] softkey.
1 Channel display: Display of the plug position for the relevant param-
eter
The red bar indicates for each connected sensor to which plug posi-
tion (channel) of the meter it is connected.
1. In the measured value display:
Display the sensor data (sensor name, serial number) with [Info].
