inoLab
®
Multi 9620 IDS pH value
ba77173e04 12/2017 37
Calibration evalua-
tion
After calibrating, the meter automatically evaluates the calibration. The zero
point and slope are evaluated separately. The worse evaluation of both is taken
into account. The evaluation appears on the display and in the calibration
record.
Menu item Setting/
function
Explanation
Calibration /
Calibration data stor-
age / Display
- Displays the calibration records.
Further options:
 Scroll through the calibration
records with <><>.
 Using <PRT>, output the dis-
played calibration record to the
interface USB-B (USB Device,
e.g. PC) or USB-A (USB Host,
e.g. USB printer).
 Using <PRT_>, output all calibra-
tion records to the interface USB-
B (USB Device, e.g. PC) or USB-
A (USB Host, e.g. USB printer).
 Quit the display with <ESC>.
 Switch directly to the measured
value display with <M>.
Calibration /
Calibration data stor-
age / Output to USB
flash drive or printer
- Outputs the stored calibration data to
the USB-A interface (USB Host, e.g.
USB memory device/USB printer).
Calibration /
Calibration data stor-
age / Output to
RS232/USB
- Outputs the stored calibration data to
the USB-B interface (USB Device,
e.g. PC)
Display Calibration
record
Zero point
[mV]
Slope [mV/pH]
+++
-15 ... +15 -60.5 ... -58.0
++
-20 ... <-15
or
>+15 ... +20
>-58.0 ... -57.0
+
-25 ... <-20
or
>+20 ... +25
-61.0 ... <-60.5
or
>-57.0 ... -56.0
