wtw inoLab Multi 9620 IDS User Manual

Ion concentration inoLab
®
Multi 9620 IDS
54 ba77173e04 12/2017
Calibration evalua-
tion
After calibrating, the meter automatically evaluates the calibration.
Menu item Setting/
function
Explanation
Calibration /
Calibration data stor-
age / Display
- Displays the calibration records.
Further options:
 Scroll through the calibration
records with <><>.
 Using <PRT>, output the dis-
played calibration record to the
interface USB-B (USB Device,
e.g. PC) or USB-A (USB Host,
e.g. USB printer).
 Using <PRT_>, output all calibra-
tion records to the interface USB-
B (USB Device, e.g. PC) or USB-
A (USB Host, e.g. USB printer).
 Quit the display with <ESC>.
 Switch directly to the measured
value display with <M>.
Calibration /
Calibration data stor-
age / Output to USB
flash drive or printer
- Outputs the stored calibration data to
the USB-A interface (USB Host, e.g.
USB memory device or USB printer).
Calibration /
Calibration data stor-
age / Output to
RS232/USB
- Outputs the stored calibration data to
the USB-B interface (USB Device,
e.g. PC)
Display Calibration record Magnitude of the slope [mV]
+++ 30.0 ... 90.0 *
or 15.0 ... 45.0 **
Error Error < 30 or > 90 *
or < 15 or > 45 **
Error elimination (see section
15.2 ISE, page 127)
* Monovalent ions
** Bivalent ions
