Dissolved oxygen inoLab
®
Multi 9620 IDS
78 ba77173e04 12/2017
Displaying the cali-
bration record
The calibration record of the last calibration is available in the menu Calibration
/ Calibration record. To open it in the measured value display, press the
<CAL_> key.
The calibration records of the last 10 calibrations are available in the menu Cali-
bration / Calibration data storage / Display. To open the Calibration menu in the
measured value display, press the <ENTER> key.
Calibration evalua-
tion
After calibration, the meter automatically evaluates the current status of the
calibration. The evaluation appears on the display and in the calibration record.
Menu item Setting/
function
Explanation
Calibration /
Calibration data
storage / Display
- Displays the calibration records.
Further options:
 Scroll through the calibration
records with <><>.
 Using <PRT>, output the dis-
played calibration record to the
interface USB-B (USB Device,
e.g. PC) or USB-A (USB Host,
e.g. USB printer).
 Using <PRT_>, output all cali-
bration records to the interface
USB-B (USB Device, e.g. PC) or
USB-A (USB Host, e.g. USB
printer).
 Quit the display with <ESC>.
 Switch directly to the measured
value display with <M>.
Calibration /
Calibration data
storage / Output to
USB flash drive or
printer
- Outputs the stored calibration data
to the USB-A interface (USB Host,
e.g. USB memory device/USB
printer).
Calibration /
Calibration data
storage / Output to
RS232/USB
- Outputs the stored calibration data
to the USB-B interface (USB
Device, e.g. PC)
For evaluation, the characteristic curve of the sensor that was
determined is compared to the characteristic curve of an ideal sen-
sor at similar environmental conditions (relative slope S):
S = S
sensor
/ S
ideal sensor
.
An ideal sensor has a slope of 1.
