Xerox Phaser 3500 Service Manual

Parts List
Phaser® 3500 Laser Printer Service Manual
5-5
16 ELA UNIT EXIT SOLENOID 121N01100
17 ELA UNIT DEVE MOTOR 127N07389
18 ELA UNIT MAIN MOTOR 127N07390
19 PBA MAIN (Main Board) 140N63016
20 MEA UNIT GEAR PICK UP 007N01361
20.1 GEAR M PICK UP CAM
20.2 GEAR M PICK UP
20.3 SPRINT ETC CAM MP
21 MEA UNIT GEAR P/UP MP CARDINAL 007K13470
21.1 GEAR MP HOLDER CAM
21.2 GEAR MP PICK UP
21.3 SPRING ETC CAM MP
22 BEARING PICK UP
23 BRACKET P SHAFT MP
24 MEP CLUTCH FEED 121N01101
25 SOLENOID MAIN 121E19250
26 SOLENOID MP 121N01102
27 RING E
28 SHIELD P SMPS
29 SMPS V1 HVPS - 110V
SMPS V2 HVPS - 220V
105N02059
105N02060
30 BAR P CROSS BOTTOM
31 FAN DC 127E14630
32 STOPPER M FAN80
34 ELA UNIT DEVE (Print Cartridge)
6K Toner Cartridge
12K Toner Cartridge
106R01148
106R01149
35 ELA UNIT CASSETTE (Tray 2) 109R00756
36 ELA UNIT SCF (Optional Tray 3) 050N00476
37 ELA UNIT DUPLEX 084N00718
38 BRACKET P DUMMY CTRL 015N00555
39 ELA HOU NPCE High (Network Interface Card) 140N63021
Main Assembly (Continued)
Item No. Description Qty Part Number
