Parts List
Phaser® 3500 Laser Printer Service Manual
5-18
PL 8.4 Parts List Table
Fuser Assembly
Item No. Description Qty Part Number
1 ELA UNIT FUSER 110V
ELA UNIT FUSER 220V
126N00242
126N00243
1-1 COVER M FUSER UPPER
1-2 THERMOSTAT (ELECTRODE P FU L)
1-3 THERMISTOR
1-4 PMO GUIDE CLAW GREEN
1-5 SPRING TS
1-6 SPRING SEPARATION
1-7 MEC BRUSH ANTISTATIC
1-8 ELECTRODE P FU R
1-9 HOLDER M IDLE ROLLER
1-10 PMO ROLLER UPPER DP
1-11 HOLDER M LEVER L
1-12 HOLDER M LEVER R
1-13 ELECTRODE P SUPPORT
1-14 SCREW
1-15 SCREW
1-16 ROLLER HEAT
1-17 BALL BEARING
1-18 CAP M END
1-19 BUSH HR
1-20 GEAR M FUSER Z49
1-21 STOPPER SPACER
1-22 ELECTRODE FU
1-23 SPRING ETC GUIDE DEVE
1-24 CAP M ACTUATOR UP
1-25 COVER M REAR GUIDE UP
1-26 ELECTRODE P SU CARBON
1-27 IEX SHAFT IDLE F/UP
1-28 HOLDER P SL CONNECTOR
