Repairs and Adjustments
Phaser® 3500 Laser Printer
Service Manual
4-20
Feed2 Idle Unit
1.
Remov
e:
■
T
ray 1 (MPT) Assembly
on page
4-12
■
Retard Assembly
on page
4-18
■
T
ray 1 Separator (Holder) P
ad Assembly
on page
4-19
2.
Remov
e 4 scre
ws, 2 for each of the feed idle units.
3.
Remov
e each idle unit.
Feed2 Idle Unit
s3500-067
64
66
