Parts List
Phaser® 3500 Laser Printer Service Manual
5-8
PL 8.2 Parts List Table
Cover Assembly
Item No. Description Qty Part Number
1 (1-X) AS UNIT COVER TOP 002N02411
1-1 COVER M TOP
1-2 COVER M OPEN XRX
1-3 PMO STACKER RX 002N02418
1-4 LEVER M STACKING 38 036N00030
1-5 STOPPER M HINGE OPEN
1-6 COVER M OP PANEL XRX
1-7 SHEET OVERLAY BUTTON
1-8 MEC BRUSH ANTISTATIC
1-9 PBA SUB PANEL B’D 123N00241
1-10 KEY M BUTTON XRX
1-11 KEY M CANCEL
1-12 CAP M LED XRX
1-13 WINDOW M LCD
1-14 GROUND TOP COVER
2 COVER M LEFT 002N02413
3 COVER M RIGHT 002N02414
4 COVER M CONTROL BOX 002N02419
5 COVER M FRONT INNER 002N02415
6 MEA UNIT COVER REAR 002N02416
6.1 COVER M REAR
6.2 PMO STACKER REAR
6.3 ICT BRKT REAR COVER
6.4 GUIDE M EXIT
6.5 PMO STRIPE 001N00462
6.7 PEX ROLLER F/UP(2)
6.8 SPRING ETC SEPARATION
6.9 LABEL(P) JAM REMOVAL
7 CO VER M FRAME EXIT 002N02417
8 COVER M DUMMY DUP (FILLER PANEL) 002N02420
To Next Page
