Xerox Phaser 3500 Service Manual

General Information and Specifications
Phaser® 3500 Laser Printer Service Manual
6-4
Parts of the Printer
Front View
Rear View
Control Panel
Control Board cover
On/Off Switch
Paper Gauge
Tray 2
Tray 1 (MPT) Release
Tray 1 (MPT)
Paper Output Support
Output Tray
Print Cartridge
s3500-013
Rear Door
Duplex Unit
(optional)
Power Cord Receptacle
Tray 3 Optional
Cable Connector
IEEE 1284 Parallel Port
USB Port
Network Port
(optional for 3500B)
s3500-014

Xerox Phaser 3500 Specifications

General

Brand	Xerox
Model	Phaser 3500
Category	Printer
Language	English
