Xerox Phaser 3500 Service Manual

Repair Analysis Procedures
Phaser® 3500 Laser Printer Service Manual
2-16
Output Tray Is Full
2.
1. Use diagnostics to check the laser
motor function.
2. Did the laser motor fail?
Replace the Laser
Unit.
Replace the Main
Board.
Step Actions and Questions Yes No
1.
1. Check the Output Tray sensor and
actuator for obvious damage.
2. Is the actuator damaged?
Replace the actuator. Go to Step 2.
2.
1. Use diagnostics to test the output tray
sensor.
2. Does the sensor operate correctly?
Replace the Main
Board.
Replace the Output
Tray S enso r.
Step Actions and Questions Yes No
