Parts List
Phaser® 3500 Laser Printer Service Manual
5-4
PL 8.1 Parts List Table
Main Assembly
Item No. Description Qty Part Number
1 ELA UNIT FRAME BASE
2 ELA HOU BASE HOUSING
3 MEA UNIT KNOCK UP MP 050N00475
3.1 PLATE M KNOCK UP MP
3.2 MPR PAD KNOCK UP MP
3.3 PMO SIDE GUIDE MP R
3.4 PMO SIDE GUIDE MP L
3.5 GEAR PINION
3.6 SHAFT REINFORCEMENT
4 MEA UNIT COVER MP XRX 002N02410
4.1 COVER M MP XRX
4.2 TRAY M EXTND MP
5 TRAY M LINK MP L 012N00521
6 TRAY M LINK MP R 012N00522
7 ROLLER TRANSFER 022E29520
8 ELA UNIT HOLDER TR R 019E63470
8.1 PMO BUSHING TR
8.2 SPRING ETC TR R HAWK
8.3 PMO TRANSFER HOLDER
8.4 IPR PLATE TR
9 ELA UNIT HOLDER TR L 019E63480
9.1 PMO BUSHING TR
9.2 SPRING ETC TR R HAWK
9.3 PMO TRANSFER HOLDER
10 PMO CAP TR 021N02248
11 GEAR TR29 (Transfer) 007N01013
12 ELA UNIT REGI (Registration Assembly) 022N02171
13 GEAR REGI Z25 007N01360
14 CAP M GEAR 807E06450
15 UNIT LSU (Laser Unit) 122N00242
To Next Page
