Xerox Phaser 3500 Service Manual

Repair Analysis Procedures
Phaser® 3500 Laser Printer Service Manual
2-13
4.
1. Inspect the Duplex Assembly. Is any
paper wrapped around the Duplex
rollers?
Remove obstruction
and clean rollers.
Go to Step 5.
5.
1. Use service diagnostics to check the
exit sensor.
2. Does the sensor operate correctly?
Go to Step 6. Replace the exit
sensor and/or
actuator.
6.
1. Inspect the exit and duplex roller
assemblies.
2. Are the rollers damaged or binding?
Replace the exit or
duplex roller as
necessary.
Go to Step 7.
7.
1. Inspect the duplex assembly for
damage.
Replace the duplex
assembly.
Go to Step 8.
8.
1. Does the Feed Roller Assembly
operate properly without binding?
Replace Main Board. Replace the Feed
Roller Assembly.
Step Actions and Questions Yes No
