Troubleshooting
Phaser 3330 and WorkCentre 3335/3345 Xerox Internal Use Only
Service Manual
2-26
20-500 Memory Full The memory has become
full.
Either delete unnecessary
documents, or retransmit
after more memory
becomes available, or split
the transmission into
more than one operation.
20-550 Low Memory Available Fax Memory is
getting low.
Fax Memory is almost full.
Print or remove received
fax Job.
20-600 No answer. When the machine could not
connect to the remote
machine after Completion of
re-dial up to re-dial counter
in system data.
The remote machine did not
answer after all the re-dial
attempts.
Try again. Make sure the
remote machine is OK.
20-700 Number Not
assigned
The speed dial location you
tried to use has no number
assigned to it.
Dial the number manually
with the keypad, or assign
the number.
20-800 Power failure while
sending or receiving
fax
When the machines’s max
memory has not been
backed up and there is a
power on/off.
Try sending/receiving the
fax again.
20-900 Retry Re-dial The machine is waiting for
the programmed interval to
automatically re-dial.
Press Start to immediately
re-dial, or Stop to cancel
the re-dial operation.
Network Configuration Errors
02-100 Invalid/Unknown
USB Device
Not a valid USB device. The
memory type appears to be
incorrect. Only SCSI type
memory can be supported.
Use a valid USB Device.
02-200 Check USB Memory Out of room or device not
responding.
Check memory and try
again.
17-100 IP Address is
conflicted
Two devices are trying to use
the same IP address.
Obtain new IP address. IP Conflict
17-110 Connection error Failed to connect to
designated server.
Retry connecting to server.
If problem persists contact
the network administrator.
17-120 Server not found Machine cannot connect to
the designated server.
Check that the network
cable is connected.
Contact the network
administrator.
Error Error Message Cause Initial Action Go To
To Next Page
