Xerox WorkCentre 5021 Service Documentation

08/2012
6-4
WorkCentre 5021/5019
6.1.2, 6.1.3
Initial Issue
General Procedures
6.1.2 Standard Specification of IIT, IOT, and PANEL
The standard specification of Engine part is as follows:
6.1.3 Standard Specification of Controller
The standard specification of Controller as follows:
Table 1
20 PPM 18 PPM
IIT - CCD Image Sensor capable of sca-
ninig at multi-level 600 dpi
- CCD Image Sensor capable of scaninig
at multi-level 600 dpi
IOT - 20 PPM- 600x600 dpi - Paper Feed-
ing:
• 1 tray 250 sheets
• MSI 100 sheets
- Paper Output:
• Face down tray (250 paper capac-
ity)
- Duplex: Factory Option
- 18 PPM- 600x600 dpi - Paper Feeding:
• 1 tray 250 sheets
• MSI 100 sheets
- Paper Output:
• Face down tray (250 paper capacity)
- Duplex: Factory Option
PANEL - Fixed LCD - Fixed LCD
Table 1
Item Controller
CPU - Z4310 (300MHz)
Standard Memory - ROM: 4MB
- RAM: 128MB
- EEPROM: Main: 8KB, Back-up: 8KB
Extended slot - Not support

Xerox WorkCentre 5021 Specifications

General

Print Technology	Laser
Print Speed	Up to 20 ppm
Copy Speed	Up to 20 cpm
Copy Resolution	Up to 600 x 600 dpi
Scan Resolution	Up to 600 x 600 dpi
Paper Capacity	250 sheets
Monthly Duty Cycle	Up to 20, 000 pages
Connectivity	USB 2.0
Functions	Print, Copy, Scan
Maximum Paper Size	A3
Duplex Printing	Manual
Memory	128 MB
Fax Transmission Speed	33.6 Kbps (optional)
Operating System Compatibility	Windows, Mac
Print Resolution	600 x 600 dpi
