08/2012
6-5
WorkCentre 5021/5019
6.1.4, 6.1.5
General Procedures
Initial Issue
6.1.4 Standard Specification of Host I/F
The standard specification of Host I/F as follows:
NOTE: Foreign I/F: not support
6.1.5 Operating Modes
The following 4 operating modes are available.
*1: Applies to the International Energy Star Program.
6.1.5.1 IOT States
The IOT systems are in the following states in each mode.
Table 1
Item Description
Host I/F - USB(2.0)
• Apply to Full Speed (12Mbps) and High Speed (480Mbps) according to
USB host version.
• Not apply to Low Speed (1.5Mbps).
Table 1
Mode State
Running Mode The data receiving/image creation/recording (printing) operation mode
Ready Mode When the system can enter the Running Mode immediately
Low Power Mode The mode that reduces the power consumption more than the Ready
Mode
Sleep Mode *1 The mode that reduces the power consumption further more than the
Low Power Mode
Table 2
Running Mode Ready Mode
Low Power
Mode
Sleep
Mode Power OFF
Fusing System
(Fusing Unit)
Maintaining the
operating tem-
perature
Maintaining the
standby tem-
perature
Stop state Stop state Stop state
Recording System
(Transfer/Develop-
ment)
Operating state Stop state Stop state Stop state Stop state
ROS Assembly Operating state Stop state Stop state Stop state Stop state
ESS/MCU PWB
(Reference)
Operating state Standby Standby Ready to
receive
Stop state
To Next Page
