08/2012
6-10
WorkCentre 5021/5019
6.1.9, 6.1.10
Initial Issue
General Procedures
6.1.9 Operating Air Pressure
The machine shall operate properly when it is isntalled in a location at altitudes of 0-8200 feet
(0-2500 meters). However, the IOT requires some adujustments when it is installed in a loca-
tion at an altitude higher than 1000 meters.
6.1.10 Electrical Characteristics
Specifies the power supply operating voltage/frequency and the power consumption.
6.1.10.1 Operating Voltage and Frequency of Power
• The power consumption of the system is as follows, and complies with 'Energy Star'.
*: Power consumption is specified assuming full configuration
6.1.10.2 Rated Power Consumption
Rated power consumption is as follows:
6.1.10.3 TEC method
Table 1
Input Voltage Frequency (Hz)
Rated input
current Max (A)
Power
Consumption*
Spec (VA)
110-127V 127+10%
110-10%
50/60 +/- 3 Hz 12A 1676 VA (Max)
220-240V 240+10%
220-10%
50/60 +/- 3 Hz 6A 1584 VA(Max)
Table 2
Mode Power consumption Configuration
Low-power mode CPS: 45W or less45W or less (20cpm)
(18cpm)
Sleep mode (Off mode) CPS: 3.0 W or less 3.0 W or less (20cpm)
(18cpm)
Plug-in Off mode 0.5 W of less
Table 3
Configuration TEC (KWh/week)
CP 20ppm 2.3
CP 18ppm 2.5
