08/2012
6-31
WorkCentre 5021/5019
6.3.2.1
General Procedures
Initial Issue
6.3.2.1 DADF Output Component Check List
Table 1 DADF Output Component Check List
Chain-Link Component Name Connecter Level Description
005-004 DADF FEED MOTOR
CW 82.5 mm/s
- Drives the DADF FEED MOTOR at 82.5 mm/s in CW direction.
Turns ON for 50 s -> Auto OFF
005-005 DADF FEED MOTOR
CW 110.0 mm/s
- Drives the DADF FEED MOTOR at 110.0 mm/s in CW direction.
Turns ON for 50 s -> Auto OFF
005-008 DADF FEED MOTOR
CW 165.0 mm/s
- Drives the DADF FEED MOTOR at 165.0 mm/s in CW direction.
Turns ON for 50 s -> Auto OFF
005-010 DADF FEED MOTOR
CW 220.0 mm/s
- Drives the DADF FEED MOTOR at 220.0 mm/s in CW direction.
Turns ON for 50 s -> Auto OFF
005-015 DADF FEED MOTOR
CW 330.0 mm/s
- Drives the DADF FEED MOTOR at 330.0 mm/s in CW direction.
Turns ON for 50 s -> Auto OFF
005-046 DADF FEED MOTOR
CCW 82.5 mm/s
- Drives the DADF FEED MOTOR at 82.5 mm/s in CCW direction.
Turns ON for 50 s -> Auto OFF
005-047 DADF FEED MOTOR
CCW 110.0 mm/s
- Drives the DADF FEED MOTOR at 110.0 mm/s in CCW direction.
Turns ON for 50 s -> Auto OFF
005-048 DADF FEED MOTOR
CCW 165.0 mm/s
- Drives the DADF FEED MOTOR at 165.0 mm/s in CCW direction.
Turns ON for 50 s -> Auto OFF
005-049 DADF FEED MOTOR
CCW 220.0 mm/s
- Drives the DADF FEED MOTOR at 220.0 mm/s in CCW direction.
Turns ON for 50 s -> Auto OFF
005-062 DADF FEED CLUTCH - Drives the DADF FEED CLUTCH.
Turns ON for 3 s -> Auto OFF
005-072 EXIT NIP RELEASE SOLENOID L L: Turns ON the EXIT NIP RELEASE SOLENOID.
Turns ON for 3 s -> Auto OFF
005-083 DOCUMENT READY L L: Turns ON the DOCUMENT READY signal.
005-088 Image Area ON - Turns ON the Image Area signal for 5 s.
005-098 TAKEAWAY CLUTCH - Turns ON the TAKEAWAY CLUTCH for 3 s.
To Next Page
