08/2012
6-32
WorkCentre 5021/5019
6.3.2.2
Initial Issue
General Procedures
6.3.2.2 IIT Output Component Check List
6.3.2.3 IOT Output Component Check List
Table 1 IIT Output Component Check List
Chain-Link Component Name Connecter Level Description Remarks
062-002 IIT Exposure Lamp L L: Turns ON the IIT Exposure Lamp.
Turns the Lamp ON for 180 s -> Auto OFF
Will also turn OFF when Stop is instructed before
Auto OFF.
062-005 CARRIAGE MOTOR (Scan
direction)
4 phases eachH/L
switch
Moves it 50 mm from current position in Scan direction -> Auto OFF Will not accept Stop instruction before Auto OFF.
062-006 CARRIAGE MOTOR (Return
direction)
4 phases eachH/L
switch
Moves it 50 mm from current position in Return direction -> Auto OFF Will not accept Stop instruction before Auto OFF.
062-091 Exchange to DADF L Turns ON the document exchange command signal to the DADF.
Table 1 IOT Output Component Check List
Chain-Link Component Name Connector Level Description
042-001 MAIN DRIVE MOTOR On L L: Drives the MAIN DRIVE MOTOR.
042-002 NOHAD FAN (High Speed) - Drives the NOHAD FAN at high speed.
042-003 NOHAD FAN (Low Speed) - Drives the NOHAD FAN at low speed.
071-001 REGI. CLUTCH On L L: Turns ON the REGI CLUTCH.
071-002 DUPLEX CLUTCH On L L: Turns ON the DUPLEX CLUTCH.
071-003 INVERT MOTOR (CW Phase1-2) - Drives the INVERT MOTOR in CW Phase 1-2.
071-004 INVERT MOTOR (CW Phase2) - Drives the INVERT MOTOR in CW Phase 2.
071-005 INVERT MOTOR (CCW Phase1-2) - Drives the INVERT MOTOR in CCW Phase 1-2.
071-006 INVERT MOTOR (CCW Phase2) - Drives the INVERT MOTOR in CCW Phase 2.
072-001 TRAY 1 FEED CLUTCH On L L: Turns ON the TRAY 1 FEED CLUTCH.
072-002 TRAY 2 FEED/LIFT UP MOTOR (Feed) - Performs the Paper Feed operation using TRAY 2 FEED/LIFT UP MOTOR.
072-003 STM TAKEAWAY ROLL CLUTCH On L L: Turns ON the STM TAKEAWAY ROLL CLUTCH.
072-004 STM TAKEAWAY MOTOR On L L: Drives the STM TAKEAWAY MOTOR.
072-005 TRAY 2 FEED/LIFT UP MOTOR (Lift Up) - Performs the Tray Lift Up operation using TRAY 2 FEED/LIFT UP MOTOR.
072-006 MSI FEED CLUTCH On L L: Turns ON the MSI FEED CLUTCH.
091-001 Xero Combination - Carries out combined operation of the following components.
• BCR AC Bias On
• BCR DC Bias On
• DEVE DC Bias On
• MAIN DRIVE MOTOR On
• BTR -Bias On
091-002 BCR AC Bias On - Turns ON the BCR AC Bias.
091-003 BCR DC Bias On - Turns ON the BCR DC Bias.
091-004 DEVE DC Bias On - Turns ON the DEVE DC Bias.
091-005 BCR AC DC Bias On - Turns ON the AC and DC BCR Bias.
092-001 TONER DISPENSE MOTOR On L L: Drives the TONER DISPENSE MOTOR.
094-001 BTR +Bias On - Turns ON the BTR positive bias.
To Next Page
