Xerox WorkCentre 5021 Service Documentation

08/2012
6-40
WorkCentre 5021/5019
6.3.5
Initial Issue
General Procedures
711-024 DADF Lead Reg. Adjustment (Side 2) (82.5
mm/s)
105-135 120 0.1 mm 1) Default Value: 0 mm
(When 711-141 value is Default and 711-024 value is 120)
2) Adjustment Range (when 711-141 value is Default)
: +1.5 mm (105 pulse) / -1.5 mm (135 pulse)
3) Adjustment Range (when 711-141 value is 80 to 230)
: +5.5 mm (80 pulse) / -12.5 mm (230 pulse)
711-041 DADF Tail Edge Adjustment (Side 1) (220.0
mm/s)
0-255 151 0.0718 mm Default Value: 0 mm (151 pulse), +10.8 mm (-151 pulse) / -7.5 mm (+104 pulse)
Tail Edge adjustment = Lead Regi adjustment value + Tail Edge fine adjustment value
711-042 DADF Tail Edge Adjustment (Side 1) (165.0
mm/s)
0-255 151 0.0718 mm Default Value: 0 mm (151 pulse), +10.8 mm (-151 pulse) / -7.5 mm (+104 pulse)
Tail Edge adjustment = Lead Regi adjustment value + Tail Edge fine adjustment value
711-043 DADF Tail Edge Adjustment (Side 1) (110.0
mm/s)
0-255 151 0.0718 mm Default Value: 0 mm (151 pulse), +10.8 mm (-151 pulse) / -7.5 mm (+104 pulse)
Tail Edge adjustment = Lead Regi adjustment value + Tail Edge fine adjustment value
711-044 DADF Tail Edge Adjustment (Side 1) (82.5
mm/s)
0-255 151 0.0718 mm Default Value: 0 mm (151 pulse), +10.8 mm (-151 pulse) / -7.5 mm (+104 pulse)
Tail Edge adjustment = Lead Regi adjustment value + Tail Edge fine adjustment value
711-061 DADF Tail Edge Adjustment (Side 2) (220.0
mm/s)
0-255 151 0.0718 mm Default Value: 0 mm (151 pulse), +10.8 mm (-151 pulse) / -7.5 mm (+104 pulse)
Tail Edge adjustment = Lead Regi adjustment value + Tail Edge fine adjustment value
711-062 DADF Tail Edge Adjustment (Side 2) (165.0
mm/s)
0-255 151 0.0718 mm Default Value: 0 mm (151 pulse), +10.8 mm (-151 pulse) / -7.5 mm (+104 pulse)
Tail Edge adjustment = Lead Regi adjustment value + Tail Edge fine adjustment value
711-063 DADF Tail Edge Adjustment (Side 2) (110.0
mm/s)
0-255 151 0.0718 mm Default Value: 0 mm (151 pulse), +10.8 mm (-151 pulse) / -7.5 mm (+104 pulse)
Tail Edge adjustment = Lead Regi adjustment value + Tail Edge fine adjustment value
711-064 DADF Tail Edge Adjustment (Side 2) (82.5
mm/s)
0-255 151 0.0718 mm Default Value: 0 mm (151 pulse), +10.8 mm (-151 pulse) / -7.5 mm (+104 pulse)
Tail Edge adjustment = Lead Regi adjustment value + Tail Edge fine adjustment value
711-081 Vertical Reduce/Enlarge Fine Adjustment 1
(High:TBD,Mid:220.0 mm/s, Low:TBD)
0-40 20 0.001 Default Value: 0% (20), +/-2% (+/-20), 0.1% increments
Adjusts only the Top Speed for Feed Motor.
711-082 Vertical Reduce/Enlarge Fine Adjustment 2
(High:TBD,Mid:165.0 mm/s, Low:TBD)
0-40 20 0.001 Default Value: 0% (20), +/-2% (+/-20), 0.1% increments
Adjusts only the Top Speed for Feed Motor.
711-083 Vertical Reduce/Enlarge Fine Adjustment 3
(High:TBD,Mid:110.0 mm/s, Low:TBD)
0-40 20 0.001 Default Value: 0% (20), +/-2% (+/-20), 0.1% increments
Adjusts only the Top Speed for Feed Motor.
711-084 Vertical Reduce/Enlarge Fine Adjustment 4
(High:TBD,Mid:82.5 mm/s, Low:TBD)
0-40 20 0.001 Default Value: 0% (20), +/-2% (+/-20), 0.1% increments
Adjusts only the Top Speed for Feed Motor.
711-140 DADF Lead Regi Offset NVM(Side 1) 80-230 120 0.1 mm Default Value: 0 mm (120 pulse), +4.0 mm (80 pulse) / -11.0 mm (230 pulse)
711-141 DADF Lead Regi Offset NVM(Side 2) 80-230 120 0.1 mm Default Value: 0 mm (120 pulse), +4.0 mm (80 pulse) / -11.0 mm (230 pulse)
711-142 DADF Tail Edge Replace All NVM (Side 1) 0-255 151 0.0718 mm
(x2 for Soft)
Default Value: 0 mm (151 pulse), +10.8 mm (-151 pulse) / -7.5 mm (+104 pulse)
Rewrites all data of 711-041 to 711-044 with the specified data.
711-143 DADF Tail Edge Replace All NVM (Side 2) 0-255 151 0.0718 mm
(x2 for Soft)
Default Value: 0 mm (151 pulse), +10.8 mm (-151 pulse) / -7.5 mm (+104 pulse)
Rewrites all data of 711-061 to 711-064 with the specified data.
711-144 Vertical Ratio Fine Adjustment - Replace All 0-40 20 0.001 Default Value: 0% (20), +/-2% (+/-20), 0.1% increments
Adjusts only the Top Speed for Feed Motor.
Rewrites all data of 711-081 to 711-084 with the specified data.
711-150 Loop Amount Adjustment (Side 1) (x1 Pulse) 0-9 6 40 Pulse Feed Roll Step: 0.026112
NVM 1Count: 0.026112 * 40 = 1.044 mm
711-151 Loop Amount Adjustment (Side 2) (x6 Pulse) 0-14 5 30 Pulse Exit Roll Step: 0.035904
NVM 1Count: 0.035904 * 30 = 1.077 mm
Table 1 NVM DADF
Chain-Link NVM Name
Setting
Range
Default
Value step Description

Xerox WorkCentre 5021 Specifications

General

Print Technology	Laser
Print Speed	Up to 20 ppm
Copy Speed	Up to 20 cpm
Copy Resolution	Up to 600 x 600 dpi
Scan Resolution	Up to 600 x 600 dpi
Paper Capacity	250 sheets
Monthly Duty Cycle	Up to 20, 000 pages
Connectivity	USB 2.0
Functions	Print, Copy, Scan
Maximum Paper Size	A3
Duplex Printing	Manual
Memory	128 MB
Fax Transmission Speed	33.6 Kbps (optional)
Operating System Compatibility	Windows, Mac
Print Resolution	600 x 600 dpi
