Xerox WorkCentre 5021 Service Documentation

08/2012
6-39
WorkCentre 5021/5019
6.3.5
General Procedures
Initial Issue
6.3.5 NVM DADF
Table 1 NVM DADF
Chain-Link NVM Name
Setting
Range
Default
Value step Description
711-001 DADF Lead Reg. Adjustment (Side 1) (220.0
mm/s)
105-135 120 0.1 mm 1) Default Value: 0 mm
(When 711-140 value is Default and 711-001 value is 120)
2) Adjustment Range (when 711-140 value is Default)
: +1.5 mm (105 pulse) / -1.5 mm (135 pulse)
3) Adjustment Range (when 711-140 value is 80 to 230)
: +5.5 mm (80 pulse) / -12.5 mm (230 pulse)
711-002 DADF Lead Reg. Adjustment (Side 1) (165.0
mm/s)
105-135 120 0.1 mm 1) Default Value: 0 mm
(When 711-140 value is Default and 711-002 value is 120)
2) Adjustment Range (when 711-140 value is Default)
: +1.5 mm (105 pulse) / -1.5 mm (135 pulse)
3) Adjustment Range (when 711-140 value is 80 to 230)
: +5.5 mm (80 pulse) / -12.5 mm (230 pulse)
711-003 DADF Lead Reg. Adjustment (Side 1) (110.0
mm/s)
105-135 120 0.1 mm 1) Default Value: 0 mm
(When 711-140 value is Default and 711-003 value is 120)
2) Adjustment Range (when 711-140 value is Default)
: +1.5 mm (105 pulse) / -1.5 mm (135 pulse)
3) Adjustment Range (when 711-140 value is 80 to 230)
: +5.5 mm (80 pulse) / -12.5 mm (230 pulse)
711-004 DADF Lead Reg. Adjustment (Side 1) (82.5
mm/s)
105-135 120 0.1 mm 1) Default Value: 0 mm
(When 711-140 value is Default and 711-004 value is 120)
2) Adjustment Range (when 711-140 value is Default)
: +1.5 mm (105 pulse) / -1.5 mm (135 pulse)
3) Adjustment Range (when 711-140 value is 80 to 230)
: +5.5 mm (80 pulse) / -12.5 mm (230 pulse)
711-021 DADF Lead Reg. Adjustment (Side 2) (220.0
mm/s)
105-135 120 0.1 mm 1) Default Value: 0 mm
(When 711-141 value is Default and 711-021 value is 120)
2) Adjustment Range (when 711-141 value is Default)
: +1.5 mm (105 pulse) / -1.5 mm (135 pulse)
3) Adjustment Range (when 711-141 value is 80 to 230)
: +5.5 mm (80 pulse) / -12.5 mm (230 pulse)
711-022 DADF Lead Reg. Adjustment (Side 2) (165.0
mm/s)
105-135 120 0.1 mm 1) Default Value: 0 mm
(When 711-141 value is Default and 711-022 value is 120)
2) Adjustment Range (when 711-141 value is Default)
: +1.5 mm (105 pulse) / -1.5 mm (135 pulse)
3) Adjustment Range (when 711-141 value is 80 to 230)
: +5.5 mm (80 pulse) / -12.5 mm (230 pulse)
711-023 DADF Lead Reg. Adjustment (Side 2) (110.0
mm/s)
105-135 120 0.1 mm 1) Default Value: 0 mm
(When 711-141 value is Default and 711-023 value is 120)
2) Adjustment Range (when 711-141 value is Default)
: +1.5 mm (105 pulse) / -1.5 mm (135 pulse)
3) Adjustment Range (when 711-141 value is 80 to 230)
: +5.5 mm (80 pulse) / -12.5 mm (230 pulse)
