Xerox WorkCentre 5021 Service Documentation

08/2012
6-42
WorkCentre 5021/5019
6.3.5
Initial Issue
General Procedures
711-213 DADF Stamp Solenoid ON Time Adjustment 0-20 5 2 ms Default value: 10 ms, +30 ms/-4 ms, 2 ms increments
711-214 DADF Stamp Position Adjustment Side 1
(T23)
0-30 15 0.5 mm Default Value: 0 mm, +7.5 mm/-7.5 mm, approx. 0.5 mm increments
Default Value is 10 mm from Tail Edge
711-215 DADF Stamp Position Adjustment Side 2
(T28)
0-40 20 0.2 mm Sets the adjustment time so that the distance (step distance) is the same for every
speed.
Adjustment Value (ms) = (NVM Input Value - NVM Default Value) / Transport Speed x
1000 x 0.2 (mm step).
711-220 Usage of DPM Control Parameter Instructed
from the Controller
0-1 1 - 0: Cont DPM Parameter Reject
1: Cont DPM Parameter Accept
711-221 DADF DPM Control Parameter 0-255 101 - 100th Digit: Drive Type (0: High, 1: Middle, 2: Low)
10th Digit: Loop Control
1st Digit: Pre Regist Speed
711-272 Side 1 Side Regi Adjustment Value
(ADF-IIT Combine Adjustment Value Data 3)
0-240 120 - Side 1 Side Regi Adjustment Value
711-274 Side 2 Side Regi Adjustment Value
(ADF-IIT Combine Adjustment Value Data 5)
0-240 120 - Side 2 Side Regi Adjustment Value
711-276 ADF-IIT Combine Adjustment Value Data 7 0-255 0 - Adjustment Value Data 7 sent to IIT during ADF-IIT Combine
711-277 ADF-IIT Combine Adjustment Value Data 8 0-255 0 - Adjustment Value Data 8 sent to IIT during ADF-IIT Combine
711-278 ADF-IIT Combine Adjustment Value Data 9 0-255 0 - Adjustment Value Data 9 sent to IIT during ADF-IIT Combine
711-279 ADF-IIT Combine Adjustment Value Data 10 0-255 0 - Adjustment Value Data 10 sent to IIT during ADF-IIT Combine
711-280 ADF-IIT Combine Adjustment Value Data 11 0-255 0 - Adjustment Value Data 11 sent to IIT during ADF-IIT Combine
711-281 ADF-IIT Combine Adjustment Value Data 12 0-255 0 - Adjustment Value Data 12 sent to IIT during ADF-IIT Combine
711-282 ADF-IIT Combine Adjustment Value Data 13 0-255 0 - Adjustment Value Data 13 sent to IIT during ADF-IIT Combine
711-283 ADF-IIT Combine Adjustment Value Data 14 0-255 0 - Adjustment Value Data 14 sent to IIT during ADF-IIT Combine
711-284 ADF-IIT Combine Adjustment Value Data 15 0-255 0 - Adjustment Value Data 15 sent to IIT during ADF-IIT Combine
711-297 Communication Fail Bypass 0-1 0 - 0: Communication Fail Bypass OFF
1: Communication Fail Bypass ON
Table 1 NVM DADF
Chain-Link NVM Name
Setting
Range
Default
Value step Description
