Xerox WorkCentre 5021 Service Documentation

08/2012
6-47
WorkCentre 5021/5019
6.3.6
General Procedures
Initial Issue
715-088 CVT FS Offset Side 3-8 (279.4) 0-240 120 O Fast Scan Regi Correction Value (0.1 mm/step) during CVT
'Factory Settings'
715-089 CVT FS Offset Side 4-8 (279.4) 0-240 120 O Fast Scan Regi Correction Value (0.1 mm/step) during CVT
'Factory Settings'
715-090 CVT FS Offset Side 3-9 (297) 0-240 120 O Fast Scan Regi Correction Value (0.1 mm/step) during CVT
'Factory Settings'
715-091 CVT FS Offset Side 4-9 (297) 0-240 120 O Fast Scan Regi Correction Value (0.1 mm/step) during CVT
'Factory Settings'
715-095 W-Ref Correction Coefficient BW-X (or
BW-K)
70-255 140 O BW-X W-Ref correction coefficient, 'Factory Settings'
715-110 CVT FS Offset Side 1 Reference
Adjustment Value
0-240 120 O Fast Scan Regi Reference Adjustment Value (0.1 mm/step) during CVT Side 1
'Factory Settings'
At Power ON, this will be overwritten by the DADF NVM (711-272) value.
715-111 CVT FS Offset Side 2 Reference
Adjustment Value
0-240 120 O Fast Scan Regi Reference Adjustment Value (0.1 mm/step) during CVT Side 2
'Factory Settings'
At Power ON, this will be overwritten by the DADF NVM (711-274) value.
715-112 CVT FS Offset Side 3 Reference
Adjustment Value
0-240 120 O Fast Scan Regi Reference Adjustment Value (0.1 mm/step) during CVT Side 3
'Factory Settings'
At Power ON, this will be overwritten by the DADF NVM (711-274) value.
715-113 CVT FS Offset Side 4 Reference
Adjustment Value
0-240 120 O Fast Scan Regi Reference Adjustment Value (0.1 mm/step) during CVT Side 4
'Factory Settings'
At Power ON, this will be overwritten by the DADF NVM (711-274) value.
715-281 HOSEI_SCAN (for images) 0-4 1 O Correction coefficient no., 'Factory Settings'
Used for parameter selection at ENL
715-307 Original Size Detection Table Switch 40913 2 O 1: Inch13-2
2: mm-2
3: mm
4: Inch13-1
5: Inch14
715-362 FL_CHK_NG_Count 0-65535 0 O Lamp Check NG Count (Reset when lamp is replaced)
715-363 FL_CHK_NG_Data 0-1023 0 O Data obtained when Lamp Check fails (Blank scan data of G compared at checking)
715-418 AOC Flow Abnormal End Count 0-255 0 O No. of times the AOC flow has ended abnormally
Table 1 NVM IIT
Chain-Link NVM Name
Setting
Range
Default
Value Read/Write Description
