Xerox WorkCentre 5021 Service Documentation

08/2012
6-46
WorkCentre 5021/5019
6.3.6
Initial Issue
General Procedures
715-067 CVT FS Offset Side 2-6 (254~257) 0-240 120 O Fast Scan Regi Correction Value (0.1 mm/step) during CVT
'Factory Settings'
715-068 CVT FS Offset Side 1-7 (266.7-267) 0-240 120 O Fast Scan Regi Correction Value (0.1 mm/step) during CVT
'Factory Settings'
715-069 CVT FS Offset Side 2-7 (266.7~267) 0-240 120 O Fast Scan Regi Correction Value (0.1 mm/step) during CVT
'Factory Settings'
715-070 CVT FS Offset Side 1-8 (279.4) 0-240 120 O Fast Scan Regi Correction Value (0.1 mm/step) during CVT
'Factory Settings'
715-071 CVT FS Offset Side 2-8 (279.4) 0-240 120 O Fast Scan Regi Correction Value (0.1 mm/step) during CVT
'Factory Settings'
715-072 CVT FS Offset Side 1-9 (297) 0-240 120 O Fast Scan Regi Correction Value (0.1 mm/step) during CVT
'Factory Settings'
715-073 CVT FS Offset Side 2-9 (297) 0-240 120 O Fast Scan Regi Correction Value (0.1 mm/step) during CVT
'Factory Settings'
715-074 CVT FS Offset Side 3-1 (139.7-148) 0-240 120 O Fast Scan Regi Correction Value (0.1 mm/step) during CVT
'Factory Settings'
715-075 CVT FS Offset Side 4-1 (139.7-148) 0-240 120 O Fast Scan Regi Correction Value (0.1 mm/step) during CVT
'Factory Settings'
715-076 CVT FS Offset Side 3-2 (182-194) 0-240 120 O Fast Scan Regi Correction Value (0.1 mm/step) during CVT
'Factory Settings'
715-077 CVT FS Offset Side 4-2 (182-194) 0-240 120 O Fast Scan Regi Correction Value (0.1 mm/step) during CVT
'Factory Settings'
715-078 CVT FS Offset Side 3-3 (203.2) 0-240 120 O Fast Scan Regi Correction Value (0.1 mm/step) during CVT
'Factory Settings'
715-079 CVT FS Offset Side 4-3 (203.2) 0-240 120 O Fast Scan Regi Correction Value (0.1 mm/step) during CVT
'Factory Settings'
715-080 CVT FS Offset Side 3-4 (210) 0-240 120 O Fast Scan Regi Correction Value (0.1 mm/step) during CVT
'Factory Settings'
715-081 CVT FS Offset Side 4-4 (210) 0-240 120 O Fast Scan Regi Correction Value (0.1 mm/step) during CVT
'Factory Settings'
715-082 CVT FS Offset Side 3-5 (214.9-215.9) 0-240 120 O Fast Scan Regi Correction Value (0.1 mm/step) during CVT
'Factory Settings'
715-083 CVT FS Offset Side 4-5 (214.9-215.9) 0-240 120 O Fast Scan Regi Correction Value (0.1 mm/step) during CVT
'Factory Settings'
715-084 CVT FS Offset Side 3-6 (254-257) 0-240 120 O Fast Scan Regi Correction Value (0.1 mm/step) during CVT
'Factory Settings'
715-085 CVT FS Offset Side 4-6 (254-257) 0-240 120 O Fast Scan Regi Correction Value (0.1 mm/step) during CVT
'Factory Settings'
715-086 CVT FS Offset Side 3-7 (266.7-267) 0-240 120 O Fast Scan Regi Correction Value (0.1 mm/step) during CVT
'Factory Settings'
715-087 CVT FS Offset Side 4-7 (266.7-267) 0-240 120 O Fast Scan Regi Correction Value (0.1 mm/step) during CVT
'Factory Settings'
Table 1 NVM IIT
Chain-Link NVM Name
Setting
Range
Default
Value Read/Write Description
