08/2012
6-45
WorkCentre 5021/5019
6.3.6
General Procedures
Initial Issue
715-023 Lamp Fan Low Rotation ON Time 0-60 15 O Lamp Fan low rotation ON time (Unit: min)
715-024 Lamp Fan Stop Time 0-60 0 O Lamp Fan stop time (Unit: min)
715-025 FL Timer Set 0-1 0 O 0: Standard FL Timer Setting (30 min rest/0.5 s ON)
1: Condensation Mode Setting (Function with the timer settings in Diag 715-026 and 715-027)
715-026 Lamp ON Interval 0-60 30 O Interval setting (Unit: min)
715-027 Lamp ON Time 0-60 1 O Lamp ON time setting (Unit: s)
715-030 IIT Faulty Parts Diagnosis 0-65535 0 O Writing 1 starts the IIT Faulty Parts Diagnosis.
After that, the write value of this NVM will be changed from '1' to the presumed faulty Parts No.
After the Faulty Part Diagnosis has completed, reading this NVM displays the presumed faulty Part
No.
When a Fail occurs during the Faulty Part Diagnosis, the Faulty Part Diagnosis ends after the Fail
code is recorded in this NVM.
* If other than '1' has been written, it will follow the usual NVM-Write operation.
(Faulty Parts Diagnosis will not be performed)
715-050 Platen SS Registration Adjustment 16-184 100 O Regi Correction in Slow Scan Direction
'Factory Settings'
715-051 Platen SS Reduce / Enlarge Adjust-
ment
44-56 50 O Slow Scan Direction Regi Correction Value (0.1% increments)
'Factory Settings'
715-053 Platen FS Registration Adjustment 0-240 120 O Fast Scan Regi Correction Value (Dot)
VLSS=PROMVLSS+(PRadjF -120)X2
'Factory Settings'
715-056 CVT FS Offset Side 1-1 (139.7-148) 0-240 120 O Fast Scan Regi Correction Value (0.1 mm/step) during CVT
'Factory Settings'
715-057 CVT FS Offset Side 2-1 (139.7~148) 0-240 120 O Fast Scan Regi Correction Value (0.1 mm/step) during CVT
'Factory Settings'
715-058 CVT FS Offset Side 1-2 (182-194) 0-240 120 O Fast Scan Regi Correction Value (0.1 mm/step) during CVT
'Factory Settings'
715-059 CVT FS Offset Side 2-2 (182~194) 0-240 120 O Fast Scan Regi Correction Value (0.1 mm/step) during CVT
'Factory Settings'
715-060 CVT FS Offset Side 1-3 (203.2) 0-240 120 O Fast Scan Regi Correction Value (0.1 mm/step) during CVT
'Factory Settings'
715-061 CVT FS Offset Side 2-3 (203.2) 0-240 120 O Fast Scan Regi Correction Value (0.1 mm/step) during CVT
'Factory Settings'
715-062 CVT FS Offset Side 1-4 (210) 0-240 120 O Fast Scan Regi Correction Value (0.1 mm/step) during CVT
'Factory Settings'
715-063 CVT FS Offset Side 2-4 (210) 0-240 120 O Fast Scan Regi Correction Value (0.1 mm/step) during CVT
'Factory Settings'
715-064 CVT FS Offset Side 1-5 (214.9-215.9) 0-240 120 O Fast Scan Regi Correction Value (0.1 mm/step) during CVT
'Factory Settings'
715-065 CVT FS Offset Side 2-5 (214.9~215.9) 0-240 120 O Fast Scan Regi Correction Value (0.1 mm/step) during CVT
'Factory Settings'
715-066 CVT FS Offset Side 1-6 (254-257) 0-240 120 O Fast Scan Regi Correction Value (0.1 mm/step) during CVT
'Factory Settings'
Table 1 NVM IIT
Chain-Link NVM Name
Setting
Range
Default
Value Read/Write Description
To Next Page
