Xerox WorkCentre 5021 Service Documentation

08/2012
6-51
WorkCentre 5021/5019
6.3.8
General Procedures
Initial Issue
6.3.8 NVM DRIVE & NOHAD
Table 1 NVM DRIVE & NOHAD
Chain-Link NVM Name
Setting
Range
(Minimum
Value)
Setting
Range
(Maximum
Value)
Default
Value
Write
Yes/No
Initialization
Yes/No Description
741-001 DRV_MAIN_MOTOR_SPEED 1040000 1562000 1301028 Enable Enable main motor speed
(Unit: Ref CLK)
741-002 NOHAD_PRINT_STOP_DELAY 15 1800 15 Enable Enable The time for Fan high speed rotation after printing has
completed.
(Unit: 1 s)
741-003 NOHAD_STBY_MODE_INTVAL 1 20 1 Enable Enable The temperature sampling time for Fusing Fan Tempera-
ture Control.
(Unit: 1 s)
741-004 NOHAD_STBY_MODE_COUNT_THRESHOLD 1 20 3 Enable Enable The threshold count for determining the mode transition of
the Fusing Fan Temperature Control.
(Unit: times)
741-005 NOHAD_STBY_MODE_TEMP_THRESHOLD 0 800 245 Enable Enable The threshold temperature for determining the mode tran-
sition of the Fusing Fan Temperature Control.
(Unit: 0.1 degrees C)
741-006 NOHAD_STBY_MODE_SWITCH 0 1 1 Enable Enable Fusing Fan Temperature Control Execution Switch
0: Do not perform
1: Perform
741-007 NOHAD_COLD_MODE_TEMP_THRESHOLD 0 300 140 Enable Enable The threshold temperature for determining the Fan Low
Temperature Stop Operation.
(Unit: 0.1 degrees C)
741-008 NOHAD_COLD_MODE_HOLD_TIME 0 180 0 Enable Enable The time to maintain the Fan in low speed rotation for Fan
Low Temperature Stop Operation.
(Unit: 1 s)
741-027 NOHAD_CONDENSE_SWITCH 0 1 0 Enable Enable Condensation Mode Execution Switch
0: Do not perform
1: Perform
741-028 NOHAD_CONDENSE_ENTRY_TEMP_THRESHOLD 0 300 120 Enable Enable The threshold temperature for determining whether to
transition to the Condensation Mode.
(Unit: 0.1 degrees C)
741-029 NOHAD_CONDENSE_HOLD_TIME 0 240 90 Enable Enable The time where the transition to the Sleep Mode is prohib-
ited after entering the Condensation Mode.
(Unit: min)
741-030 NOHAD_SMELL_FILTER_SWITCH 0 1 0 Enable Enable Deodorant Filter Availability Switch
0: No Deodorant Filter
1: Deodorant Filter available
741-032 NOHAD_FAN_FAIL_START_TIMER 0 60 6 Enable Enable The time where Fail Detection is prohibited after the Fan
operation.
(Unit: 1 s)
741-033 NOHAD_FAN_FAIL_SUMPLE_TIME_THRESHOLD 10 300 48 Enable Enable Fan Fail Signal Accumulated Time
(Unit: 1 s)

Xerox WorkCentre 5021 Specifications

General

Print Technology	Laser
Print Speed	Up to 20 ppm
Copy Speed	Up to 20 cpm
Copy Resolution	Up to 600 x 600 dpi
Scan Resolution	Up to 600 x 600 dpi
Paper Capacity	250 sheets
Monthly Duty Cycle	Up to 20, 000 pages
Connectivity	USB 2.0
Functions	Print, Copy, Scan
Maximum Paper Size	A3
Duplex Printing	Manual
Memory	128 MB
Fax Transmission Speed	33.6 Kbps (optional)
Operating System Compatibility	Windows, Mac
Print Resolution	600 x 600 dpi
