Xerox WorkCentre 5021 Service Documentation

08/2012
6-59
WorkCentre 5021/5019
6.3.12
General Procedures
Initial Issue
6.3.12 NVM XERO
Table 1 NVM XERO
Chain-Link NVM Name
Setting
Range
(Minimum
Value)
Setting
Range
(Maximum
Value)
Default
Value
Write
Yes/No
Initialization
Yes/No Description
745-015 XERO_TEMP_DATA -20 60 18 Enable Enable Stores the temperature detection result.
(Unit: 1 degrees C)
745-097 XERO_BTR_OUTPUT_SIDE1_BIAS 0 200 80 Enable Enable Stores the BTR Output (Side 1)
(Unit: 0.1 MicroAmp)
745-098 XERO_BTR_OUTPUT_SIDE2_BIAS 0 200 80 Enable Enable Stores the BTR Output (Side 2)
(Unit: 0.1 MicroAmp)
745-100 XERO_BTR_CORR_COEF_PLAIN_SIDE1 0 200 100 Enable Disable BTR Output Correction Coefficient (for Plain Side 1)
(Unit: %)
745-101 XERO_BTR_CORR_COEF_PLAIN_SIDE2 0 200 100 Enable Disable BTR Output Correction Coefficient (for Plain Side 2)
(Unit: %)
745-102 XERO_BTR_CORR_COEF_HEAVY_SIDE1 0 200 100 Enable Disable BTR Output Correction Coefficient (for Heavyweight Side 1)
(Unit: %)
745-103 XERO_BTR_CORR_COEF_HEAVY_SIDE2 0 200 100 Enable Disable BTR Output Correction Coefficient (for Heavyweight Side 2)
(Unit: %)
745-104 XERO_BTR_NET_OUTPUT_SIDE1_BIAS 0 200 80 Enable Enable Stores the BTR Final Output (for Side 1)
(Unit: 0.1 MicroAmp)
745-105 XERO_BTR_NET_OUTPUT_SIDE2_BIAS 0 200 80 Enable Enable Stores the BTR Final Output (for Side 2)
(Unit: 0.1 MicroAmp)
750-001 XERO_BCR_AC_IO_BIAS 0 222 121 Enable Disable BCR-AC I/O Check Output Value
(Unit: 3.95 MicroAmp)
750-002 XERO_BCR_DC_IO_BIAS 0 100 74 Enable Disable BCR-DC I/O Check Output Value
(Unit: 1%)
750-003 XERO_DEVE_IO_BIAS 0 100 86 Enable Disable Deve-DC I/O Check Output Value
(Unit: 1%)
750-023 XERO_DRUM_CYCLE 0 8000000 0 Disable Enable Drum Cycle
(Unit: 0.1 cycle)
750-024 XERO_DRUM_PV 0 200000 0 Disable Enable Drum PV
(Unit: 1 sheet)
750-025 XERO_TOTAL_DRUM_CYCLE 0 4294967295 0 Enable Enable M/C Total Cycle
(Unit: 0.1 cycle)
750-026 XERO_TOTAL_DRUM_PV 0 4294967295 0 Enable Enable M/C Total PV
(Unit: 1 sheet)
750-051 XERO_DRUM_PRE_NEAR_CYCLE_DATA 0 65535 0 Enable Enable Cycle Count When Pre Near Occurs
(Unit: 100 cycle)
750-052 XERO_DRUM_PRE_NEAR_PV_DATA 0 65535 0 Enable Enable PV When Pre Near Occurs
(Unit: 100 sheet)
750-053 XERO_DRUM_PRE_NEAR_TICK_DATA 0 5000 0 Enable Enable Remaining Film Thickness When Pre Near Occurs
(Unit: 0.01 Micrometer)
