Xerox WorkCentre 5021 Service Documentation

08/2012
6-63
WorkCentre 5021/5019
6.3.14
General Procedures
Initial Issue
6.3.14 NVM PROCON
Table 1 NVM PROCON
Chain-Link NVM Name
Setting
Range
(Minimum
Value)
Setting
Range
(Maximum
Value)
Default
Value
Write
Yes/No
Initialization
Yes/No Description
752-007 PRC_CRU_EMPTY_STATE 0 3 0 Enable Enable Flag empty detection state
0: Normal
1: PreNear
2: NearEmpty
3: Empty
752-010 PRC_DRUM_CYCLE_COUNT 0 1023 0 Enable Enable Drum Rotation Time(Cycle Count)
uint32_t
752-011 PRC_DRUM_LIFE_INFO 0 4 0 Enable Enable Drum Cartridge Status(NVM. 0 to 4)
0: Normal
1: Pre-near
2: Near
3: Over
4: End
752-015 PRC_TEMP_NOW -10 80 0 Enable Enable temp_now (temperature)
752-053 PRC_ATC_AVE 0 999 0 Enable Enable ATC Average Value
752-054 PRC_ATC_AMP 0 999 0 Enable Enable ATC Amplitude
752-055 PRC_ATC_AVE_FAIL 0 1 0 Enable Enable ATC Average Fail
0: Normal
1: Fail
752-056 PRC_ATC_AMP_FAIL 0 1 0 Enable Enable ATC Amplitude Fail
0: Normal
1: Amplitude too small
752-057 PRC_ATC_WARNING 0 1 0 Enable Enable ATCwarning
752-058 PRC_ATC_WARNING_CNT 0 65535 0 Enable Enable ATC Warning Counter
752-059 PRC_ATC_FAIL 0 1 0 Enable Enable ATCFail
752-060 PRC_ATC_FAIL_CONTINUED_CNT 0 255 0 Enable Enable ATC Fail Continuous Count
752-061 PRC_ATC_AVE_FAIL_CNT 0 65535 0 Enable Enable ATC Average Fail Count
752-062 PRC_ATC_AMP_FAIL_CNT 0 65535 0 Enable Enable ATC Amplitude Fail Count
752-063 PRC_ATC_FAIL_CNT 0 65535 0 Enable Enable Number of ATC Fails
752-080 PRC_ATC_DOUBLE_AVE_PRE 0 999 548 Enable Enable ATC_2 Weighted Average Value_Previous
752-081 PRC_ATC_DOUBLE_AVE 0 999 548 Enable Enable ATC_2 Weighted Average Value
752-082 PRC_DELTA_ATC_TARGET_DIFF -999 999 0 Enable Enable Delta ATC_Target Deference
752-083 PRC_TEMP_SNR 0 1023 0 Enable Enable Temperature Sensor Value
752-086 PRC_TEMP_SNR_FAIL 0 1 0 Enable Enable Temperature Sensor Fail
0: Normal
1: Fail
752-087 PRC_TEMP_SNR_FAIL_CNT 0 65535 0 Enable Enable Temperature Sensor Fail Count
752-094 PRC_MAX_TEMP -20 60 0 Enable Enable Maximum temperature value
(Unit: 1 degrees C)
