Xerox WorkCentre 5021 Service Documentation

08/2012
6-64
WorkCentre 5021/5019
6.3.14
Initial Issue
General Procedures
752-097 PRC_IMAGE_PIXEL_HI 0 16383 0 Enable Enable Image_Pixel_Hi
752-098 PRC_IMAGE_PIXEL_LO 0 65535 0 Enable Enable Image_Pixel_Lo
752-101 PRC_ACCUM_USE_ICDC_ACCUM 0 2147483648 0 Enable Enable ICDC Accumulated Value for Measuring Accumu-
lated Usage
752-107 PRC_ICDC_MOVE_AVE_ACCUM_FEW 0 32767 0 Enable Enable ICDC Moving Average Accumulated Value [Minority]
752-108 PRC_ICDC_MOVE_AVE_ACCUM_MANY 0 32767 0 Enable Enable ICDC Moving Average Accumulated Value [Majority]
752-111 PRC_ICDC_MOVE_AVE_FEW 0 1023 0 Enable Enable ICDC Moving Average Value [Minority]
752-112 PRC_ICDC_MOVE_AVE_MANY 0 1023 0 Enable Enable ICDC Moving Average Value [Majority]
752-140 PRC_DISP_TONER_REMAIN_CORR_COEF 0 255 0 Enable Enable Disp Remaining Toner Correction Coefficient
752-159 PRC_DELTA_ATC_TARGET_TEMP_CORR -999 999 0 Enable Enable Delta ATC Target Temperature Correction Amount
752-160 PRC_DELTA_ATC_TARGET_HUMI_CORR -999 999 0 Enable Enable Delta ATC Target Humidity Correction Amount
752-173 PRC_DELTA_AGE_ATC 0 255 0 Enable Enable Delta Age_ATC
752-176 PRC_DELTA_ATC_TARGET_DEVE_CORR -999 999 0 Enable Enable Delta ATC Target Deve Correction Amount
752-186 PRC_DELTA_ATC_TARGET_AC_CORR -32768 32767 0 Enable Enable Delta ATC Target AC Correction Amount
752-188 PRC_ATC_MOD_TARGET 0 999 548 Enable Enable ATC Correction Target Value
752-192 PRC_DELTA_ATC_TARGET_MANUAL_CORR -512 511 0 Enable Enable Delta ATC Target Manual Correction Amount
752-224 PRC_BCR_DC_OUT 0 1000 735 Enable Enable BCR_DC_OUT
(0 ~ 1000 : -0 ~ -1000V)
752-225 PRC_BIAS_DC_OUT 0 255 220 Enable Enable BIAS_DC_OUT
(0 ~ 255 : 0 ~ -700V)
752-226 PRC_LD_OUT 0 255 185 Enable Enable LD_OUT
(0 ~ 255 : 0 ~ 2V)
752-230 PRC_DELTA_LD_MANUAL_CORR -100 100 0 Enable Enable Delta LD_Manual Correction Amount
(0 ~ 255 : 0 ~ 2V)
752-248 PRC_DELTA_VH_TEMP -128 127 0 Enable Enable Delta VHtemp
752-278 PRC_DELTA_VH_PR -128 127 0 Enable Enable Delta VHpr
752-301 PRC_DELTA_LD_TEMP -128 127 0 Enable Enable Delta LDtemp
752-317 PRC_DELTA_LD_HUMI -128 127 0 Enable Enable Delta LDhum
752-331 PRC_DELTA_LD_PR -128 127 0 Enable Enable Delta LDpr
752-344 PRC_DELTA_LD_EMP -128 127 0 Enable Enable Delta LDemp
752-350 PRC_DELTA_LD_MANUAL_CORR_MAX 0 100 0 disable Enable Delta LD_Manual Correction Amount Upper Limit
752-351 PRC_DELTA_LD_MANUAL_CORR_MIN -100 100 0 disable Enable Delta LD_Manual Correction Amount Lower Limit
752-352 PRC_DELTA_LD -128 127 0 Enable Enable Delta LD
752-398 PRC_FLAG_EMPTY_CHECK_STATE_ATC 0 3 0 Enable Enable Flag ATC empty detection state
0: Normal
1: Empty detection count in progress
2: NearEmpty
3: Empty
752-402 PRC_ATC_EMPTY_CHECK_STATE1_CNT 0 65535 0 Enable Enable ATC empty detection state 1 count
752-403 PRC_BUFFER_EMPTY_CHECK_CNT -30000 30000 0 Enable Enable Buffer empty detection count
Table 1 NVM PROCON
Chain-Link NVM Name
Setting
Range
(Minimum
Value)
Setting
Range
(Maximum
Value)
Default
Value
Write
Yes/No
Initialization
Yes/No Description
