Xerox WorkCentre 5021 Service Documentation

08/2012
6-74
WorkCentre 5021/5019
6.3.16
Initial Issue
General Procedures
780-017 (For PAPER_CLASS = AP/GCO) - - - 2 O O 1: 11x17S
2: A3S
3: 8K(GCO)S
5: B4S
6: 8.5x14S
7: 8.5x13S
9: A4S
10: 8.5x11S
11: 16K(GCO)S
14: B5S
16: 8.5x11L
18: A4L
19: A5S
20: 16K(GCO)L
23: B5L
780-017 (For PAPER_CLASS = XE/DMO-E) - - - 2 O O 1: 11x17S
2: A3S
5: B4S
6: 8.5x14S
7: 8.5x13S
9: A4S
10: 8.5x11S
14: B5S
16: 8.5x11L
18: A4L
19: A5S
23: B5L
780-018 IOT_MSI_PAPER_TYPE 502 - - 0 O O 0: Plain
2: Heavyweight
5: Lightweight
780-266 UIPANEL_DRUM_ALERT_PHASE1 207 0 2 1 O O 0: Do not display
1: Display only after the power had been turned OFF and ON
2: Display only when the Auto Reset Timer had timed-out
780-267 UIPANEL_DRUM_ALERT_PHASE2 208 0 2 2 O O 0: Do not display
1: Display only after the power had been turned OFF and ON
2: Display only when the Auto Reset Timer had timed-out
790-004 UIPANEL_TONER_ALERT 209 0 2 1 O O 0: Do not display
1: Display only after the power had been turned OFF and ON
2: Display only when the Auto Reset Timer had timed-out
Table 1 NVM SYSTEM
Chain-Link NVM Name
Tools
P#
Setting
Range
(Minimum
Value)
Setting
Range
(Maximum
Value)
Default
Value
Write
Allowed/
Protected
Default
Value
Yes/No Description
