08/2012
6-76
WorkCentre 5021/5019
6.3.17
Initial Issue
General Procedures
680-410 IPS_CL_BALANCE_DEF_K_MEDIUM_ DEN-
SITY
- 0 8 4 O O Default Color Balance Adjustment Level K Color Medium Den-
sity
680-411 IPS_CL_BALANCE_DEF_K_HIGH_ DENSITY - 0 8 4 O O Default Color Balance Adjustment Level K Color High Density
680-412 IPS_PLT_JOB_RAE_SS_NOT_DETECT_
AREA
- 0 65535 0 O O For Speed Priority Background Suppression/Slow Scan Non-
detection Area Platen Jobs
Slow Scan Non-detection Area Setup Value BASE at Real Time
AE for Platen Jobs.
680-413 IPS_ADF_JOB_RAE_SS_NOT_DETECT_
AREA
- 0 65535 0 O O For Speed Priority Background Suppression/Slow Scan Non-
detection Area ADF/DADF Jobs.
Slow Scan Non-detection Area Setup Value BASE at Real Time
AE for ADF/DADF Jobs.
680-414 IPS_DENSITY_ADJUSTMENT_FLAG_FOR_
ORIGINAL_TYPE_OF_COPY
- 0 7 0 O O Density Fine Adjustment Flag - Copy Document Type
bit [0]: Text, bit [1]: Photo & Text, bit [2]: Photo
1: Enabled, 0: Disabled
680-415 IPS_DENSITY_ADJUSTMENT_FLAG_FOR_
DENSITY_LEVEL_OF_COPY
- 0 63 0 O O Density Fine Adjustment Flag - Copy Density Level
bit [0]: Lighten +2 to bit [4]: Darken +2
1: Enabled, 0: Disabled
680-416 IPS_DENSITY_ADJUSTMENT_FLAG_FOR_
ORIGINAL_TYPE_OF_BW_SCAN_AND_FAX
- 0 7 0 O O Density Fine Adjustment Flag - BW Scan/Fax Document Type
bit [0]: Text, bit [1]: Photo & Text, bit [2]: Photo
1: Enabled, 0: Disabled
680-417 IPS_DENSITY_ADJUSTMENT_FLAG_FOR_
DENSITY_LEVEL_OF_BW_SCAN_AND_FAX
- 0 63 0 O O Density Fine Adjustment Flag - BW Scan/Fax Density Level
bit [0]: Lighten +2 to bit [4]: Darken +2
1: Enabled, 0: Disabled
680-418 IPS_DENSITY_ADJUSTMENT_
PARAMETER_A_FOR_COPY
- 0 255 64 O O Density Fine Adjustment Slant A for Copy.
Slant A fixed decimal format. bit [6] corresponds to coefficient
1.
680-419 IPS_DENSITY_ADJUSTMENT_
PARAMETER_B_FOR_COPY
- 0 255 0 O O Density Fine Adjustment Section B for Copy.
The section B negative is specified with 2 complements.
680-420 IPS_DENSITY_ADJUSTMENT_
PARAMETER_A_FOR_BW_SCAN_AND_FAX
- 0 255 64 O O Density Fine Adjustment Slant A for BW Scan/Fax.
Slant A fixed decimal format. bit [6] corresponds to coefficient
1.
680-421 IPS_DENSITY_ADJUSTMENT_
PARAMETER_B_FOR_BW_SCAN_AND_FAX
- 0 255 0 O O Density Fine Adjustment Section B for BW Scan/Fax.
The section B negative is specified with 2 complements.
680-422 IPS_FULL_COLOR_SCAN_SATURATION_A
DJUSTMENT
- 0 4 2 O O Saturation Adjustment for Full Color Scan.
0: Pastel +2
1: Pastel +1
2: Normal
3: Vivid +1
4: Vivid +2
Table 1 NVM IPS
Chain-Link NVM Name
Tools
P#
Setting
Range
(Minimum
Value)
Setting
Range
(Maximum
Value)
Default
Value
Write
Allowed/
Protected
Default
Value
Yes/No Description
