Virtex-5 RocketIO GTP Transceiver User Guide www.xilinx.com 135

UG196 (v1.3) May 25, 2007

RX OOB/Beacon Signaling

Longest idle width that must be accepted for

COMWAKE

112 5.6 8.4 5.6 5.6 5.6 4.8

MaxWakeWidth 7 11 7 7 7 6

Longest idle width that must be rejected for

COMWAKE

175 8.8 13.1 8.8 8.8 8.8 7.5

Table 7-8: Example SATA Attribute Settings (Continued)

Parameter ns cycles cycles cycles cycles cycles cycles
