Virtex-5 RocketIO GTP Transceiver User Guide www.xilinx.com 97

UG196 (v1.3) May 25, 2007

FPGA TX Interface

Figure 6-8: REFCLKOUT Driving Multiple Transceivers with a 2-Byte Interface

GTP

Transceiver

GTP_DUAL

Tile

GTP

Transceiver

UG196_c6_08_040907

PLL_BASE

CLKIN

RST

CLKOUT0

REFCLKOUT

PLLLKDET

TXUSRCLK2

TXUSRCLK

TXUSRCLK2

TXUSRCLK

TXDATA (16 or 20 bits)

CLKOUT1

LOCKED

TXDATA (16 or 20 bits)

Design in

FPGA

BUFG
