Yamaha E40J - Page 159

6F65G11
7-10
9
8
7
6
5
4
3
2
1
Upper case, pivot shaft
6F67035E
14 N·m (1.4 kgf·m, 10 ft·lb)
24 N·m (2.4 kgf·m, 17.7 ft·lb)
No. Part name Q’ty Remarks
1 Bolt 2 M8 × 30 mm
2 Bolt 2 M8 × 35 mm
3 Steering bracket 1
4 Dowel 2
5 Pivot shaft 1
6 Washer 1
7 Bushing 1
8 Straight key 1
9 Spring 1
10 Rubber seal 1
11 Bolt 1 M8 × 25 mm
12 Bushing 1
13 Oil seal 1
14 Washer 1
15 Mount housing 1
16 Clamp 1
17 Bolt 4 M8 × 45 mm
Not reusable
