Yamaha E40J - Page 158

BRKT
7-9
6F65G11
Bracket unit
6F67030E
28 N·m (2.8 kgf·m, 20 ft·lb)
55 N·m (5.5 kgf·m, 40 ft·lb)
No. Part name Q’ty Remarks
18 Protector 1
19 Upper case assembly 1
20 Circlip 1
21 Bushing 1 E40J:L and Y transom models
22 Bolt 2 M8 × 130 mm
23 Washer 2
24 Washer 2
25 Seal 2
26 Lock tie 2
27 Seal 2
28 Nut 4
