Yamaha E40J - Page 164

BRKT
7-15
6F65G11
Bracket unit
6F67050E
45 N·m (4.5 kgf·m, 33 ft·lb)
45 N·m (4.5 kgf·m, 33 ft·lb)
24 N·m (2.4 kgf·m, 17.7 ft·lb)
10 N·m (1.0 kgf·m, 7.2 ft·lb)
No. Part name Q’ty Remarks
18 Washer 1
19 Wave washer 2
20 Pin 2
21 Circlip 2
22 Tilt stopper plate (starboard side) 1
23 Grease nipple 4
24 Bushing 2
25 Plate 1
26 Tilt stopper plate (port side) 1
27 Swivel bracket 1
