6F65G11
5-8
9
8
7
6
5
4
3
2
1
Power unit
6F65040E
4 N·m (0.4 kgf·m, 3.0 ft·lb)
29 N·m (2.9 kgf·m, 21 ft·lb)
No. Part name Q’ty Remarks
1 Starter motor 1
2 Starter relay 1
3 Bracket 1
4 Bolt 2 M6 × 12 mm
5 Spiral tube 1
6 Cap 3
7 Nut 3
8 Spring washer 3
9 Starter motor lead 1
10 Battery negative lead 1
11 Bolt 2 M8 × 16 mm
12 Washer 2
13 Collar 2
14 Bracket 1
15 Bracket 1
16 CDI unit 1
17 Bolt 2 M6 × 20 mm
All components are for WH and W models only.
