Yamaha E40J - Page 64

POWR
5-9
6F65G11
Power unit
6F65040E
4 N·m (0.4 kgf·m, 3.0 ft·lb)
29 N·m (2.9 kgf·m, 21 ft·lb)
No. Part name Q’ty Remarks
18 Rectifier 1
19 Screw 1 ø6 × 25 mm
20 Bolt 1 M6 × 16 mm
21 Battery positive lead 1
22 Cap 1
All components are for WH and W models only.
