Yamaha E40J - Page 66

POWR
5-11
6F65G11
Power unit
6F65020E
10 N·m (1.0 kgf·m, 7.2 ft·lb)
15 N·m (1.5 kgf·m, 11.1 ft·lb)
No. Part name Q’ty Remarks
1 Manual starter case 1
2 Spiral spring 1
3 Washer 1
4 Sheave drum 1
5 Spring 1
6 Drive pawl 1
7 Spring 1
8 Washer 1
9 Drive plate 1
10 Washer 1
11 Bolt 1 M8 × 30 mm
12 Collar 1
13 Nut 1
14 Bolt 1 M6 × 20 mm
15 Collar 1
16 Roller 1
17 Bolt 2 M6 × 16 mm
