Yamaha E40J - Page 78

POWR
5-23
6F65G11
Power unit
6F65080E
15 N·m (1.5 kgf·m, 11.1 ft·lb)
30 N·m (3.0 kgf·m, 22 ft·lb)
12 N·m (1.2 kgf·m, 8.7 ft·lb)
25 N·m (2.5 kgf·m, 18 ft·lb)
8 N·m (0.8 kgf·m, 5.8 ft·lb)
No. Part name Q’ty Remarks
18 Cylinder head cover 1
19 Gasket 1
20 Screw 1
21 Anode 1
22 Bolt 16 M6 × 25 mm
23 Exhaust outer cover 1
24 Gasket 1
25 Exhaust inner cover 1
26 Gasket 1
27 Hose 1
Not reusable
Not reusable
Not reusable
