1-7
FEATURES
QS
The quick shift system indicators are divided into
QS and QS sections.
QS and QS are not linked and can be inde-
pendently turned on or off.
QS can be set to ON or OFF.
OFF turns the respective upshift or downshift
function off, and the clutch lever must then be
used when shifting in that direction.
“Shift Indicator”
This module allows a custom shift indicator to be
set. When the engine r/min (rotations per min-
ute) are in the specified range, the gear indicator
will flash.
This module has 3 options:
“IND Mode” - the shift indicator can be turned
ON/OFF
“IND Start” - the r/min at which the indicator
starts flashing can be chosen.
Once selected, rotate the wheel switch up/down
to increase or decrease the r/min value by incre-
ments of 200 r/min.
“IND Start” is settable between 6000–12800 r/
min.
“IND Stop” - the r/min at which the indicator
stops flashing can be chosen.
Once selected, rotate the wheel switch up/down
to increase or decrease the r/min value by incre-
ments of 200 r/min.
“IND Stop” is settable between 6200–13000
r/min.
“Maintenance”
This module allows you to record the distance
traveled between engine oil changes (use the
OIL item), and for two other items of your choice
(use INTERVAL 1 and INTERVAL 2).
To reset a maintenance trip meter, select it and
then long push the wheel switch.
Maintenance item names cannot be changed.
“Unit”
This module allows you to switch the display be-
tween metric and imperial measurement units.
When using kilometers, the fuel consumption
units can be changed between “km/L” or “L/
100km”. When using miles, MPG will be avail-
able.
Temperature units can be switched between
Celsius and Fahrenheit.
km/h
S
hift Indicator
IND Mode ON
IND Start 8 000 r/min
IND Stop 10000 r/min
OIL
INTERVAL 1
km/h
km
1000
km
1000
km
Maintenance
INTERVAL 2 1000
km or mile km
L/100km
°C
km/L or L/100km
°C or °F
km/h
Unit
