Yamaha MT-09 2021 - Page 198

4-65
FRONT FORK
Disassembling the front fork leg
Order Job/Parts to remove Q’ty Remarks
14 Wheel axle pinch bolt 1
15 Damper rod assembly bolt 1
16 Copper washer 1
17 Damper rod assembly 1
18 Inner tube 1 Right side only.
LT
LS
LS
15
17
16
New
New
NewNew
New
New
18
New
New
14
23 N
•
m (2.3 kgf
•
m, 17 lb
•
ft)
T
.R.
15 N
•
m (1.5 kgf
•
m, 11 lb
•
ft)
T
.R.
23 N
•
m (2.3 kgf
•
m, 17 lb
•
ft)
T
.R.
