Yamaha MT-09 2021 - Page 317

5-90
TRANSMISSION
Disassembling the drive axle assembly
Order Job/Parts to remove Q’ty Remarks
16 Washer 1
17 2nd wheel gear 1
18 Collar 1
19 Collar 1
20 Bearing 1
21 Circlip 1
22 Drive axle 1
19
M
M
M
E
20
21
22
M
M
M
M
M
18
17
16
M
New
New
New
New
