9-184
P0500, P1500
• Short circuit check
Disconnect the ECU related connectors before checking.
Refer to “PARTS CONNECTED TO THE ECU” on page 9-4.
Gy
LLVP
P/WLg/LY/LL/B
B/LB/LBr/WGy/GG/LB/YL/W
W/YW/GG/WG/WL/WL/Y
Gy
LLVP
P/WLg/LO/WY/LL/B
B/LB/LBr/WGy/GG/LBr/LB/YL/W
W/YW/GG/WG/WLg/BL/WL/Y
B/Y
L/Y
Y/B B/Y
Y/W L/Y
2
**
2
*
1
4
5
3
*
3
**
B/Y
B
B/Y
W
L/W
R
L/B
LB
Sb/W
Sb
W
Br
L/W
RR
L/Y
L
L/Y
*. MTN890
**. MTN890D
Is resistance 0 Ω?
YES
→ Go to “Short circuit check”.
NO
a. Replace the wire harness.
b. Execute the diagnostic mode. (Code 21)
When the clutch lever is released with the transmission in gear and when
the sidestand is retracted
OFF
When the clutch lever is squeezed with the transmission in gear and when
the sidestand is retracted
ON
Is it correct indication?
YES
→ Go to step 21.
NO
→ Go to “Short circuit check”.
To Next Page
