9-185
P0500, P1500
Ground short circuit check “A”
Lines short circuit check “B”
Between relay unit coupler “1” and ground
black–ground
blue–ground
Relay unit coupler “1”
black–any other coupler terminal
blue–any other coupler terminal
ECU coupler “2” black/yellow–any other coupler terminal
Clutch switch coupler “3”
black/yellow–any other coupler terminal
blue/yellow–any other coupler terminal
Gy
LLVP
P/WLg/LY/LL/B
B/LB/LBr/WGy/GG/LB/YL/W
W/YW/GG/WG/WL/WL/Y
Gy
LLVP
P/WLg/LO/WY/LL/B
B/LB/LBr/WGy/GG/LBr/LB/YL/W
W/YW/GG/WG/WLg/BL/WL/Y
2
**
2
*
1
3
**
W
L/W
R
L/B
LB
Sb/W
Sb
W
Br
L/W
RR
1
W
L/W
R
L/B
LB
Sb/W
Sb
W
Br
L/W
RR
BA
Y/B B/Y
Y/W L/Y
3
*
B/Y
L/Y
*. MTN890
**. MTN890D
Is resistance ∞ Ω?
YES
→ Go to step 19.
NO
a. Replace the wire harness.
b. Execute the diagnostic mode. (Code 21)
When the clutch lever is released with the transmission in gear and when
the sidestand is retracted
OFF
When the clutch lever is squeezed with the transmission in gear and when
the sidestand is retracted
ON
Is it correct indication?
YES
→ Go to step 21.
NO
→ Go to step 19.
