YASKAWA SGD7S

6.11 Selecting Torque Limits
6.11.5 /CLT (Torque Limit Detection) Signal
6-71
6
Application Functions
6.11.5 /CLT (Torque Limit Detection) Signal
This section describes the /CLT signal, which indicates the status of limiting the motor output
torque.
Note: You must allocate the /CLT signal to use it. Use Pn50F = n.X (/CLT (Torque Limit Detection Output) Sig-
nal Allocation) to allocate the signal to a connector pin. Refer to the following section for details.
6.1.2 Output Signal Allocations on page 6-7
Typ e Signal Connector Pin No. Signal Status Meaning
Output /CLT Must be allocated.
ON (closed)
The motor output torque is being
limited.
OFF (open)
The motor output torque is not being
limited.
