YASKAWA SGD7S

8.13 Manual Tuning
8.13.1 Tuning the Servo Gains
8-80
Set the machine vibration frequencies in the notch filter parameters.
Pn409
First Stage Notch Filter Frequency
Setting Range Setting Unit Default Setting When Enabled Classification
50 to 5,000 1 Hz 5,000 Immediately Tuning
Pn40A
First Stage Notch Filter Q Value
Setting Range Setting Unit Default Setting When Enabled Classification
50 to 1,000 0.01 70 Immediately Tuning
Pn40B
First Stage Notch Filter Depth
Setting Range Setting Unit Default Setting When Enabled Classification
0 to 1,000 0.001 0 Immediately Tuning
Pn40C
Second Stage Notch Filter Frequency
Setting Range Setting Unit Default Setting When Enabled Classification
50 to 5,000 1 Hz 5,000 Immediately Tuning
Pn40D
Second Stage Notch Filter Q Value
Setting Range Setting Unit Default Setting When Enabled Classification
50 to 1,000 0.01 70 Immediately Tuning
Pn40E
Second Stage Notch Filter Depth
Setting Range Setting Unit Default Setting When Enabled Classification
0 to 1,000 0.001 0 Immediately Tuning
Pn417
Third Stage Notch Filter Frequency
Setting Range Setting Unit Default Setting When Enabled Classification
50 to 5,000 1 Hz 5,000 Immediately Tuning
Pn418
Third Stage Notch Filter Q Value
Setting Range Setting Unit Default Setting When Enabled Classification
50 to 1,000 0.01 70 Immediately Tuning
Pn419
Third Stage Notch Filter Depth
Setting Range Setting Unit Default Setting When Enabled Classification
0 to 1,000 0.001 0 Immediately Tuning
Pn41A
Fourth Stage Notch Filter Frequency
Setting Range Setting Unit Default Setting When Enabled Classification
50 to 5,000 1 Hz 5,000 Immediately Tuning
Pn41B
Fourth Stage Notch Filter Q Value
Setting Range Setting Unit Default Setting When Enabled Classification
50 to 1,000 0.01 70 Immediately Tuning
Pn41C
Fourth Stage Notch Filter Depth
Setting Range Setting Unit Default Setting When Enabled Classification
0 to 1,000 0.001 0 Immediately Tuning
Pn41D
Fifth Stage Notch Filter Frequency
Setting Range Setting Unit Default Setting When Enabled Classification
50 to 5,000 1 Hz 5,000 Immediately Tuning
Pn41E
Fifth Stage Notch Filter Q Value
Setting Range Setting Unit Default Setting When Enabled Classification
50 to 1,000 0.01 70 Immediately Tuning
Pn41F
Fifth Stage Notch Filter Depth
Setting Range Setting Unit Default Setting When Enabled Classification
0 to 1,000 0.001 0 Immediately Tuning
• Do not set notch filter frequencies (Pn409, Pn40C, Pn417, Pn41A, and Pn41D) that are close
to the speed loop’s response frequency. Set a frequency that is at least four times the speed
loop gain (Pn100). (However, Pn103 (Moment of Inertia Ratio) must be set correctly. If the set-
ting is not correct, vibration may occur and the machine may be damaged.
• Change the notch filter frequencies (Pn409, Pn40C, Pn417, Pn41A, and Pn41D) only while the
Servomotor is stopped. Vibration may occur if a notch filter frequency is changed during oper-
ation.
Speed
Position
Torque
Speed
Position
Torque
Speed
Position
Torque
Speed
Position
Torque
Speed
Position
Torque
Speed
Position
Torque
Speed
Position
Torque
Speed
Position
Torque
Speed
Position
Torque
Speed
Position
Torque
Speed
Position
Torque
Speed
Position
Torque
Speed
Position
Torque
Speed
Position
Torque
Speed
Position
Torque
Important
