14.2 Parameter Recording Table
14-40
* The enable timing depends on the digit that is changed. Refer to the following section for details.
14.1 List of Parameters on page 14-2
Pn52F 0FFF Monitor Display at Startup Immediately
Pn530 0000
Program Jogging-Related
Selections
Immediately
Pn531 32768
Program Jogging Travel
Distance
Immediately
Pn533 500
Program Jogging Move-
ment Speed
Immediately
Pn534 100
Program Jogging Accelera-
tion/Deceleration Time
Immediately
Pn535 100
Program Jogging Waiting
Time
Immediately
Pn536 1
Program Jogging Number
of Movements
Immediately
Pn550 0
Analog Monitor 1 Offset
Voltage
Immediately
Pn551 0
Analog Monitor 2 Offset
Voltage
Immediately
Pn552 100
Analog Monitor 1 Magnifi-
cation
Immediately
Pn553 100
Analog Monitor 2 Magnifi-
cation
Immediately
Pn55A 1
Power Consumption Moni-
tor Unit Time
Immediately
Pn560 400
Residual Vibration Detec-
tion Width
Immediately
Pn561 100 Overshoot Detection Level Immediately
Pn580 10 Zero Clamping Level Immediately
Pn581 20 Zero Speed Level Immediately
Pn582 10
Speed Coincidence Detec-
tion Signal Output Width
Immediately
Pn583 10
Brake Reference Output
Speed Level
Immediately
Pn584 10000
Speed Limit Level at Servo
ON
Immediately
Pn585 50
Program Jogging Move-
ment Speed
Immediately
Pn586 0
Motor Running Cooling
Ratio
Immediately
Pn600 0
Regenerative Resistor
Capacity
Immediately
Pn601 0
Dynamic Brake Resistor
Allowable Energy Con-
sumption
After restart
Pn603 0 Regenerative Resistance Immediately
Pn604 0 Dynamic Brake Resistance After restart
Continued from previous page.
Parameter
No.
Default Setting Name
When
Enabled
To Next Page
