2.3 External Dimensions
2.3.2 SERVOPACK External Dimensions
2-25
Duct-ventilated SERVOPACKs
Hardware Option Code: 001
• Three-phase, 200 VAC: SGD7S-470A and -550A
• Three-phase, 200 VAC: SGD7S-590A and -780A
Unit: mm
Approx. mass: 8.4 kg
4 × M5
Terminals
Terminals
8 × M5
Ground
terminals
2 × M5
210
139 (71)
350
170
(75)
Exterior
Cutout
Mounting Hole Diagram
8.5
4
145 ± 0.5
(mounting pitch)
320 min 7.5
350
315
7.5
17.5
162 min
170
335 ± 0.5 (mounting pitch)
4 × M6
Terminals
4 × M6
Terminals
8 × M6
Ground
terminals
2 × M6
260
390
(292.5)
330 min
390
30
7.5
64
(75) (75)136
260
244 min8
4.5
Unit: mm
Appr
ox. mass
: 13.8 kg
Mounting Hole Diagram
Exterio
Cutout
375 ± 0.5 (mounting pitch)
235 ± 0.5
(mounting pitch)
4 × M6
To Next Page
