YASKAWA SIGMA-7 Series User Manual

6.1 Alarm Displays
6.1.2 Troubleshooting Alarms
6-32
A.E60
*5
:
Reception Error in
MECHATROLINK
Communications
MECHATROLINK wir-
ing is not correct.
Check the MECHA-
TROLINK wiring.
Correct the
MECHATROLINK Com-
munications Cable wiring.
–
A MECHATROLINK
data reception error
occurred due to
noise.
–
Implement countermea-
sures against noise.
(Check the MECHA-
TROLINK Communica-
tions Cable and FG
wiring, and implement
measures such as attach-
ing a ferrite core to the
MECHATROLINK Com-
munications Cable.)
–
A failure occurred in
the SERVOPACK.
–
Turn the power supply to
the SERVOPACK OFF and
ON again. If the alarm still
occurs, the SERVOPACK
may be faulty. Replace the
SERVOPACK.
–
A.E61:
Synchronization
Interval Error in
MECHATROLINK
Transmission
Cycle
The MECHATROLINK
transmission cycle
fluctuated.
Check the setting of the
MECHATROLINK trans-
mission cycle.
Remove the cause of
transmission cycle fluctu-
ation at the host control-
ler.
–
A failure occurred in
the SERVOPACK.
–
Turn the power supply to
the SERVOPACK OFF and
ON again. If the alarm still
occurs, the SERVOPACK
may be faulty. Replace the
SERVOPACK.
–
A.E63:
MECHATROLINK
Synchronization
Frame Not
Received
MECHATROLINK wir-
ing is not correct.
Check the Servomotor
wiring.
Correct the MECHA-
TROLINK Communica-
tions Cable wiring.
–
A MECHATROLINK
data reception error
occurred due to
noise.
–
Implement countermea-
sures against noise.
(Check the MECHA-
TROLINK Communica-
tions Cable and FG
wiring, and implement
measures such as attach-
ing a ferrite core to the
MECHATROLINK Com-
munications Cable.)
–
A failure occurred in
the SERVOPACK.
–
Turn the power supply to
the SERVOPACK OFF and
ON again. If the alarm still
occurs, the SERVOPACK
may be faulty. Replace the
SERVOPACK.
–
Continued on next page.
Continued from previous page.
Alarm Number:
Alarm Name
Possible Cause Confirmation Correction Reference

YASKAWA SIGMA-7 Series Specifications

General

Encoder Resolution	24-bit absolute encoder
Pollution Degree	2
Cooling Method	Natural cooling or forced air cooling
Control Method	Vector control
Communication Protocols	EtherCAT, MECHATROLINK-III
Input Voltage	AC 200 V, AC 400 V
Rated Output	Varies by model
Safety Function	STO (Safe Torque Off), SS1 (Safe Stop 1), SS2 (Safe Stop 2), SLS (Safely Limited Speed), SBC (Safe Brake Control)
Power Supply Voltage	AC 200 V, AC 400 V
Rated Output Current	Varies by model
Protection Functions	Overload, overvoltage, undervoltage, overheat, short circuit
Operating Temperature	0°C to 55°C
Storage Temperature	-20°C to 65°C
Vibration Resistance	5.9 m/s² at 10 Hz to 55 Hz
Ambient Humidity	5% to 95% RH (non-condensing)
Altitude	Up to 1000 m
Installation	Panel mounted
