YASKAWA SIGMA-7 Series User Manual

7.2 List of Servo Parameters
7-47
7
Parameter Lists
Pn82D
2
Option Field Allocations
4
0000h to
1F1Ch
– 0000h All
After
restart
Setup
*13
Continued on next page.
Continued from previous page.
Parameter
No.
Size
Name
Setting
Range
Setting
Unit
Default
Setting
Applicable
Motors
When
Enabled
Classi-
fication
Refer-
ence
M2
*13
n.X
BANK_SEL1 Allocation (Option)
0 Allocate bits 0 to 3 to BANK_SEL1.
1 Allocate bits 1 to 4 to BANK_SEL1.
2 Allocate bits 2 to 5 to BANK_SEL1.
3 Allocate bits 3 to 6 to BANK_SEL1.
4 Allocate bits 4 to 7 to BANK_SEL1.
5 Allocate bits 5 to 8 to BANK_SEL1.
6 Allocate bits 6 to 9 to BANK_SEL1.
7 Allocate bits 7 to 10 to BANK_SEL1.
8 Allocate bits 8 to 11 to BANK_SEL1.
9 Allocate bits 9 to 12 to BANK_SEL1.
A Allocate bits 10 to 13 to BANK_SEL1.
B Allocate bits 11 to 14 to BANK_SEL1.
C Allocate bits 12 to 15 to BANK_SEL1.
n.X
BANK_SEL1 Allocation Enable/Disable Selection
0 Disable BANK_SEL1 allocation.
1 Enable BANK_SEL1 allocation.
n.X
LT_DISABLE Allocation (Option)
0 to F The settings are the same as for the V_PPI allocations.
n.X
LT_DISABLE Allocation Enable/Disable Selection
0 Disable LT_DISABLE allocation.
1 Enable LT_DISABLE allocation.

YASKAWA SIGMA-7 Series Specifications

General

Encoder Resolution	24-bit absolute encoder
Pollution Degree	2
Cooling Method	Natural cooling or forced air cooling
Control Method	Vector control
Communication Protocols	EtherCAT, MECHATROLINK-III
Input Voltage	AC 200 V, AC 400 V
Rated Output	Varies by model
Safety Function	STO (Safe Torque Off), SS1 (Safe Stop 1), SS2 (Safe Stop 2), SLS (Safely Limited Speed), SBC (Safe Brake Control)
Power Supply Voltage	AC 200 V, AC 400 V
Rated Output Current	Varies by model
Protection Functions	Overload, overvoltage, undervoltage, overheat, short circuit
Operating Temperature	0°C to 55°C
Storage Temperature	-20°C to 65°C
Vibration Resistance	5.9 m/s² at 10 Hz to 55 Hz
Ambient Humidity	5% to 95% RH (non-condensing)
Altitude	Up to 1000 m
Installation	Panel mounted
